Schmalz Pouch Suction Cups PSPF

The Schmalz bellows suction cup PSPF is a round 2C bellows suction cup with 3.5 folds for handling very thin and flexible bags. The snug and soft sealing lip enables an optimal seal even on bags with strong folds. This makes it the ideal suction cup for use in handling bags filled with liquids, solids or powders, especially for packaging with a low fill level, such as potato chips, infusion bags and packaged baked goods. Its high holding properties predestine it for use in highly dynamic packaging processes, especially in conjunction with delta robots (case packers and pick & place applications). The suction cup is made of food-grade silicone and can therefore be used in the food sector without hesitation.

Product Highlight

• Reliable handling of thin, flexible or liquid-filled bags
• High-strength 2C connection of bellows and sealing lip combines sophisticated material properties in one suction cup
• Supple and soft sealing lip enables optimum sealing even on bags with strong wrinkling
• Reinforced bellows with interlocking bellows ensures optimum stability and support during rapid cycles
• Suction cup made of FDA-compliant silicone is suitable for direct contact with food

Application

• Round 2K-Bellows suction cup with 3.5 Bellows for handling very thin and flexible pouches
• Use for handling liquid, solid or powder filled pouches, especially for packages with low filling level
• Use in dynamic packaging processes, especially in connection with Delta-Robots (Case-Packer and Place-Applications)
